Belt Scale Manufacturer | Electronic Belt Scale and Belt Weighing System

Reliable Belt Scale for Continuous Material Weighing

Weifang Zhitian is a professional belt scale manufacturer specializing in continuous weighing and material measurement equipment. Our belt scale is designed for accurate and reliable weighing of bulk materials during continuous conveying processes.

The system combines a weighing frame, load cells, speed sensor and ZTJL-3206intelligent weighing instrument to measure material flow rate and accumulated weight in real time. It is suitable for coal, limestone, clinker, ore, fertilizer, chemical materials, minerals and other bulk materials.

High-Performance Electronic Belt Scale

The Weifang Zhitian electronic belt scale uses high-precision load cells and a speed measurement system to provide continuous online weighing. As material passes over the weighing section, the system detects the load on the conveyor belt and calculates the instantaneous flow rate and total material quantity.

Compared with manual weighing methods, an electronic belt scale can provide continuous measurement without interrupting the production process. This makes it an effective solution for production monitoring, material management and process control.

Advanced Belt Weighing System

A complete belt weighing system normally includes a weighing bridge, load cells, speed sensor, weighing controller and related electrical components. These components work together to provide stable and accurate material measurement.

The belt weighing systemZTJL-3206 can display instantaneous flow, accumulated weight, belt speed and other operating parameters. It can also be integrated with 485 or DCS a plant control system for centralized monitoring and automatic process management.

For industries that require continuous material measurement, a reliable belt weighing system can help improve production efficiency and reduce material measurement errors. Measurement accuracy: ±0.5-1%, Flow rate: 0-1000 tons/hour，Belt width 500-2000 mm
